SKF D/W ER1634 Bearing

SKF Bearing Professional After-sales Guarantee Easy And Secure Payment D/W ER1634 Transparent And Fair Price On Time Delivery

SKF D/W ER1634 Bearing Description

We supply various of SKF D/W ER1634 bearings. bearings is purity material and high precision , the varieties of SKF bearings is up to thousands of species .SKF D/W ER1634 bearings is known as ” the food of machinery industry” and widely used in different environment and mechanical.The purpose of SKF D/W ER1634 bearings is the operation and control. In order to ensure the smooth operation and normally rotation,SKF D/W ER1634 bearings inquire deeply into the running of the machine and friction phenomenon .SKF D/W ER1634 bearings is widely used in automobile, motor, gear, injection molding machines, machine tools, mining machinery, engineering machinery, motorcycles, office equipment, paper making machinery, pumps and compressors, wind power generator and so on.The shipment of SKF D/W ER1634 bearings will be arranged timely for we have a large stock of SKF D/W ER1634 bearings in HongKong.

SKF D/W ER1634 Bearing Specification

Bearing number : D/W ER1634

Size (mm) : 19,05×25,4×3,967

Brand : The brand you need

Bore Diameter (mm) : 19,05

Outer Diameter (mm) : 25,4

Width (mm) : 3,967

Bearing dimensions and specification in ALIER catalogue:

d – 19.05 mm

D – 25.4 mm

B – 3.967 mm

d₁ – – 21.35 mm

D₁ – – 23.4 mm

D₂ – – 24 mm

r_1,2 – min. – 0.25 mm

d_a – min. – 21 mm

D_a – max. – 24.5 mm

r_a – max. – 0.25 mm

Basic dynamic load rating – C – 0.572 kN

Basic static load rating – C₀ – 0.365 kN

Fatigue load limit – P_u – 0.016 kN

Reference speed – 53000 r/min

Limiting speed – 34000 r/min

Calculation factor – k_r – 0.015

Calculation factor – f₀ – 8.6

Mass bearing – 0.0045 kg
